Industrial & Commercial PV Grid-Connected System

The Industrial & Commercial PV Grid-Connected System is specially developed for industrial and commercial energy demands. It enhances Grid adaptability through ±0.8 power factor regulation and meets the requirements of intelligent operation and maintenance with multi-protocol communication and remote upgrade functions. PID repair technology enhances the output efficiency of components. The design of AC and DC switches ensures maintenance safety. 100% international brand components provide highly reliable grid connection solutions for scenarios such as factories, hotels, and commercial buildings.

Core Features

• Strong reactive power compensation capability: Adjustable range of power factor ±0.8, optimizing grid quality.

• Flexible communication configuration: Supports RS485/ Ethernet /GPRS/Wi-Fi multiple protocols (optional combinations).

• Multiple communication interfaces: Supports RS485/Wi-Fi/GPRS remote monitoring (choose one configuration among the three).

• Remote upgrade support: Convenient system firmware update.

• Component performance improvement: Built-in PID repair technology ensures power generation efficiency.

• Safety maintenance design: Standard AC/DC disconnector, ensuring safer operation.

• Top-notch component configuration: 100% use components from internationally renowned brands to extend the system's lifespan.



Parameters

System power	3.6KW	6KW	10KW	15KW	20KW	30KW
Solar panel power	450W	430W	420W
Number of solar panels	8 PCS	14 PCS	24 PCS	36 PCS	48 PCS	72 PCS
Photovoltaic DC cable	1 SET
MC4 connector	1 SET
Rated output power of inverter	3KW	5KW	8KW	12KW	17KW	25KW
Maximum output apparent power	3.3KVA	5.5KVA	8.8KVA	13.2KVA	18.7KVA	27.5KVA
Rated grid voltage	1/N/PE.220V		3/N/PE,400V
Grid voltage range	180~276Vac		270~480Vac
Rated grid frequency	50Hz
Grid frequency range	45~55Hz
Maximum efficiency	98.20%			98.50%
Island effect protection	YES
DC reverse connection protection	YES
AC short circuit protection	YES
Leakage current protection	YES
Protection level	IP65
Working temperature	-25 ~ +60°C
Cooling method	Natural cooling
Maximum working altitude	4km
Communication	4G (optional) / WiFi (optional)
AC output copper core cable	1 SET
Distribution box	1 SET
Auxiliary material	1 SET
Photovoltaic mounting type	Aluminum /Carbon steel mounting (one set)
